VEK IP100 Veterinary Infusion Pump
The VEK IP100 Veterinary Infusion Pump is designed to provide accurate, reliable, and safe fluid and medication delivery for veterinary patients. Featuring a 4.3-inch color touchscreen, intelligent alarm system, and multiple infusion modes, it is ideal for veterinary hospitals, clinics, operating rooms, intensive care units, and emergency applications.
Key Features
- 4.3-inch color LCD touchscreen with intuitive user interface
- Compact and lightweight design for easy transport
- Compatible with a wide range of standard IV infusion sets
- Multiple infusion modes for different clinical applications
- Advanced pressure monitoring technology
- High-accuracy infusion control (±5%)
- Audible and visual alarm system
- Built-in rechargeable lithium battery
Designed for Veterinary Practice
The VEK IP100 combines precision, ease of use, and portability, allowing veterinary professionals to safely administer intravenous fluids, medications, and anesthetic support in both clinical and field environments.
Infusion Modes
- Rate + Volume (mL/h)
- Rate + Time (mL/h)
- Rate Mode
- Drop Rate + Volume (drops/min)
- Drop Rate + Time (drops/min)
- Drop Rate Mode
Technical Specifications
| Specification | Value |
|---|---|
| Display | 4.3-inch Color LCD Touchscreen |
| Compatible Infusion Sets | Compatible with multiple standard IV infusion set brands (20 drops/mL) |
| Tubing Diameter | 3.4–4.5 mm |
| Flow Rate | 0.1–1500 mL/h |
| Flow Rate Resolution | 0.1 mL/h (low range) |
| Drop Rate | 1–500 drops/min (20 drops/mL) |
| Accuracy | ±5% |
| VTBI (Volume To Be Infused) | 0.1–9999 mL |
| Bolus / Fast Infusion Rate | 1000 mL/h |
| KVO Rate | 0.1 mL/h |
| Occlusion Pressure Levels | 19, 38, 57, 76, 95, 114, and 133 kPa (Default: 95 kPa) |
| Air Bubble Detection | Ultrasonic air-in-line detection |
| Power Supply | AC 100–240 V, 50/60 Hz External DC 7.4 V |
| Battery | Built-in rechargeable 7.4 V lithium battery, 1800 mAh |
| Fuse | T1A |
| Operating Temperature | 10°C to 30°C |
| Relative Humidity | ≤70% |
| Atmospheric Pressure | 86–106 kPa |
| Dimensions | 200 × 156 × 97 mm (7.87 × 6.12 × 3.82 in) |
Safety Features
- Audible and visual alarms
- Occlusion detection
- Air-in-line detection
- Low battery alarm
- Door open alarm
- Infusion completion alarm
- System malfunction alarm
Applications
- Veterinary hospitals
- Veterinary clinics
- Surgical procedures
- Intensive Care Units (ICU)
- Emergency and critical care
- Fluid therapy
- Continuous drug infusion
